ADB3-63 DC MCB

Description

ADB3-63 DC MCB

The ANDELI ADB3-63DC DC Circuit Breaker is a reliable protection device designed for DC electrical systems and solar photovoltaic (PV) applications. It is suitable for circuits with a rated DC voltage up to 1000V and current up to 63A, providing effective protection against overload and short-circuit conditions.

This DC miniature circuit breaker is commonly used in solar PV systems, DC distribution boxes, battery systems, and inverter protection circuits. It ensures safe operation and allows infrequent manual switching of DC electrical circuits.

With a high breaking capacity of 6kA and compliance with GB/T10963.2 and IEC60898-2 international standards, the ADB3-63DC breaker ensures safety, durability, and reliable performance in demanding DC applications.

⭐ Key Features

✔ Brand: ANDELI
✔ Model: ADB3-63DC
✔ Product Type: DC Miniature Circuit Breaker (MCB)
✔ Rated Voltage: Up to 500V DC
✔ Current Range: 10A – 63A
✔ Breaking Capacity: 6kA
✔ Pole Options: 1 Pole / 2 Pole
✔ Single Pole Voltage: 250V DC
✔ Double Pole Voltage: 500V DC
✔ Application: Solar PV & DC circuits
✔ Standards: GB/T10963.2, IEC60898-2

⚡ Applications

• Solar Photovoltaic (PV) Systems

• Solar Combiner Boxes

• DC Distribution Panels

• Battery Energy Storage Systems

• DC Power Supply Circuits

• Inverter Protection Systems
